| Camera | ||||||||||
| Sensor | 1/2.8″,progressive scan,2.0 megapixel, CMOS | |||||||||
| Lens | 4.0mm@F1.6 | 6.0mm@F1.6 | ||||||||
| DORI Distance | Lens | Detect（m） | Observe（m） | Recognize（m） | Identify（m） | |||||
| 4mm | 64.3 | 25.7 | 12.9 | 6.4 | ||||||
| 6mm | 96.4 | 38.6 | 19.3 | 9.6 | ||||||
| Angle of View(H) | 78.7° | 53.3° | ||||||||
| Angle of View (V) | 42.8° | 29.3° | ||||||||
| Angle of View (O) | 96.8° | 65.5° | ||||||||
| Adjustment angle | Pan: 0°~360° | Tilt: 0°~90° | Rotate: 0°~360° | |||||||
| Shutter | Auto/Manual, 1~1/100000 s | |||||||||
| Minimum Illumination | Colour: 0.001Lux (F1.6, AGC ON) 0 Lux with IR on | |||||||||
| Day/Night | IR-cut filter with auto switch (ICR) | |||||||||
| Digital noise reduction | 2D/3D DNR | |||||||||
| S/N | >52dB | |||||||||
| IR Range | Up to 50m (164 ft) IR range | |||||||||
| Defog | Digital Defog | |||||||||
| WDR | 120dB | |||||||||
| Video | ||||||||||
| Video Compression | Ultra265, H.265, H.264, MJPEG | |||||||||
| H.264 code profile | Baseline profile, Main Profile, High Profile | |||||||||
| Frame Rate | Main Stream:2MP (1920×1080): Max. 60fps; Sub Stream: 2MP (1920×1080): Max.30 fps; Third Stream:D1 (720×576): Max. 30fps; | |||||||||
| 9:16 Corridor Mode | Supported | |||||||||
| ROI | Supported | |||||||||
| HLC | Supported | |||||||||
| OSD | Up to 8 OSDs | |||||||||
| Privacy Mask | Up to 8 areas | |||||||||
| ROI | Up to 8 areas | |||||||||
| Smart | ||||||||||
| Behavior Detection | Intrusion, cross line, motion detection | |||||||||
| Intrusion | Enter and loiter in a pre-defined virtual region | |||||||||
| cross line | Cross a pre-defined virtual line | |||||||||
| motion detection | Moving within a pre-defined virtual region | |||||||||
| Recognition: | Face detection | |||||||||
| Intelligent Identification | Defocus, Scene Change, Object Left, Object Moving | |||||||||
| Statistical Analysis | People counting | |||||||||
| General Function | Watermark, IP Address Filtering, output/input Alarm, Access Policy, ARP Protection, RTSP Authentication, User Authentication | |||||||||
| Storage | ||||||||||
| Edge Storage | Micro SD, up to 256 GB | |||||||||
| Network Storage | ANR | |||||||||
| Network | ||||||||||
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP | |||||||||
| Compatible Integration | ONVIF(Profile S, Profile G, Profile T), API | |||||||||
| Interface | ||||||||||
| Network | 1 RJ45 10M/100M Base-TX Ethernet | |||||||||
| General | ||||||||||
| Power | 12 V DC±25%, PoE (IEEE802.3 af) | |||||||||
| Power consumption: Max 7.5W | ||||||||||
| Dimensions (L × W × H) | 253.4×86×71.7 (9.98” × 3.4” × 2.8”) | |||||||||
| Weight | 1.0kg (2.2lb) | |||||||||
| Working Environment | -35°C ~ +60°C (-31°F ~ 140°F), Humidity:10%~95% RH(non-condensing) | |||||||||
| Ingress Protection | IP67 | |||||||||
| Vandal Resistant | IK10 | |||||||||
